NLIR Mid‑Infrared Spectroscopy Solutions

Neeyal EnviroSolutions is the exclusive Pan‑India distributor for NLIR (Denmark), pioneering "Mid‑Infrared Spectroscopy with Ease" via advanced upconversion technology.

Product Lineup

MIDWAVE Spectrometer

Band: 2.0 – 5.0 μm (2000–5000 cm⁻¹) optical range
Speed: Capture full spectrum in milliseconds; up to 400 Hz readout (kHz variants available)
Resolution & Sensitivity: ~6 cm⁻¹ resolving power, sensitivity down to 5 pW/nm (dark noise ~11 counts)
Design: Fibre-coupled (SMA‑905) grating spectrometer. Detects via upconversion to the visible/NIR region using CMOS array — no cryogenic cooling needed
Applications: Gas and liquid sensing, optical coatings, plastic sorting using AI, combustion monitoring, high-speed spectroscopy, etc.

Bundle Spectrometer System

Configures the NLIR upconversion module (Spektrum or Tune) with standard VIS/NIR spectrometers (e.g., Avantes or Wasatch brands) for cost-efficient MIR detection
Offers ultra-fast readout up to 1 kHz or 130 kHz, with resolution options from 3 to 2.5 cm⁻¹

Custom Spectrometer Solutions

Usable bandwidth from ~1.7 μm to 5.0 μm, with flexible configuration of exposure time, resolution, and spectral range to suit bespoke research and industrial applications

Key Technical Highlights

All instruments based on upconversion technology: convert mid‑IR radiation into near‑visible/NIR wavelengths using a nonlinear LiNbO₃ crystal and 1064 nm laser field, enabling high-speed silicon detection with superior signal-to-noise ratio

Eliminates thermal noise and removes the need for cryogenic cooling; offers exceptional sensitivity and real-time spectral feedback

Why Choose Neeyal EnviroSolutions for NLIR Instruments?

Official Reseller in India

Full sales, support, and service coverage across all states.

Turnkey Consultative Process

From application assessment to final system deployment.

End-to-End Deployment

Technical setup, software integration, validation (via NLIzeR), and staff training.

Sector-Specific Guidance

Applications: environmental monitoring, sorting, process control—based on NLIR's scientific use cases.

Get Started with NLIR via Neeyal EnviroSolutions

Pre-sales needs assessment & system specification
Technical integration with your workflows (Python/MATLAB APIs available)
Post-sales support, software deployment, and complaint management
